High-Temp Glass Digital Printers

PRODUCT DESCRIPTION：

A specialized digital printing system that replaces traditional screen printing-directly jeting high-temp ceramic inks onto glass then fusing colors with the substrate via 680-720°c sintering, Delivers 1440dpi ultra-fine detais, 3-5x faster productivity. and weather proof finishes (20+ years outdoor fade resistance, scratch-proof. ldeal for architectural curtain walls, appliance panels and custom decorative alass.

-

-

TECHNICAL PARAMETER	AG2536/AG2518	AG37200
No. of Printhead	4-12	12-24
Min ink droplet size	10pl/25pl	10pl/25pl
Colors	KCMYWG	KCMYWG
Resolution	X:360/480/720dpi Y:400/800/1600dpi	X:360/480/720dpi Y:400/800/1600dpi
Speed (high-resolution)	12printheads 24m²/h;6Printheads 12m²/h	12printheads 24m/h; 18 Printheads 32m²/h
(production)	12printheads 55m²/h;6Printheads 30m²/h	12printheads 55m/h;18 Printheads 60m²/h
(draft)	12Printheads 100m/h;6Printheads 60m²/h	12Printheads 100m/h;18 Printheads 109m²/h
Ink type	High temperature ceramic inks

PRODUCT
HIGHLIGHTS

High-temp digital print? Boom! No screen limits, 1440dpi crisp, 20+ years fade-proof.Auto ink + fast cure-prints that last, easy!
